A new day for water testing.

Get a complete and accurate view of your water quality with ZERO waste. Each cartridge comes pre-loaded with 8 or 23 different testing parameters and provides accurate data in a fraction of the time. Results display on your smartphone in real-time and can be shared immediately.

e-sens Cartridge Diagram
e-sens

The Right Data = The Right Decisions

Testing the right parameters and collecting relevant data allows you to have an accurate view of the water supply and to take swift action to fix any standards violations or public hazards and make key technology or infrastructure decisions. The e-sens Cartridge asks the right questions and gathers the most important data, making it available for analysis in real-time so you can keep your constituents safe and your organization’s reputation healthy.

Our cartridges ensure that data is actually being collected using time stamps and location coordinates.

100 Testing Cycles Per Cartridge

e-sens
e-sens

Save Time and Cost

Each e-sens Cartridge can be used for up to 100 testing cycles, saving you thousands of dollars over using expensive, dated testing methods and reducing test time drastically. e-sens also provides you with automatic cartridge reordering so you always have them in stock.

You can collect results to 3 times as many parameters in a fraction of the time.

Save Thousands Each Year!

Sales Info

e-sens

Technical Specs

8 Parameter Cartridge - Testing Parameters:

Type pH ORP Conductivity Total Dissolved Solids Weight Color
Parameters Units Operating
Range
Accuracy
(Whichever is greater)
MDL
pH 5.00 - 11.00 +/- 0.1 pH n/a n/a
ORP mV -1000 - 2000 mV n/a n/a n/a
Conductivity µS/cm 50 - 2500 µS/cm +/- 10% +/- 20 µS/cm 50 µS/cm
Total Dissolved Solids mg/L 25 - 1250 mg/L +/- 10% +/- 10 mg 25 mg/L
Free Chlorine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Monochloramine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Total Chlorine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Sample Temperature °C 2.0 - 45.0 °C +/- 10 °C +/- 1 °C 2.0 °C

* All the numerical values and percentages are subject to change.

23 Parameter Cartridge - Testing Parameters:

Type pH ORP Conductivity Total Dissolved Solids Weight Color
Parameters Units Operating
Range
Accuracy
(Whichever is greater)
MDL
pH 5.00 - 11.00 +/- 0.1 pH n/a n/a
ORP mV -1000 - 2000 mV n/a n/a n/a
Conductivity µS/cm 50 - 2500 µS/cm +/- 10% +/- 20 µS/cm 50 µS/cm
Total Dissolved Solids mg/L 25 - 1250 mg/L +/- 10% +/- 10 mg 25 mg/L
Free Chlorine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Monochloramine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Total Chlorine mg/L Cl₂ 0.05 - 5.00 mg/L +/- 10% +/- 0.10 mg/L 0.07 mg/L
Ammonium mg/L N-NH₃ 0.05 - 5.00 mg/L +/- 10% +/- 0.20 mg/L 0.05 mg/L
Free Ammonia mg/L N-NH₃ 0.05 - 5.00 mg/L +/- 10% +/- 0.20 mg/L 0.05 mg/L
Total Ammonia mg/L N-NH₃ 0.05 - 5.00 mg/L +/- 10% +/- 0.20 mg/L 0.05 mg/L
Chlorine to Ammonia Ratio 0.01 - 100.00 +/- 10% +/- 0.5 n/a
Nitrification Capacity mg/L N-NO₃ 0.05 - 10.0 mg/L +/- 10% +/- 0.20 mg/L 0.05 mg/L
Calcium Hardness mg/L CaCO₃ 5 - 1000 mg/L +/- 10% +/- 10 mg/L 5 mg/L
Total Hardness mg/L CaCO₃ 5 - 1000 mg/L +/- 10% +/- 10 mg/L 5 mg/L
Ionic Calcium mg/L Ca 3 – 400 mg/L +/- 10% +/- 5 mg/L 3 mg/L
Sample Temperature °C 2.0 - 45.0 °C +/- 10 °C +/- 1 °C 2.0 °C
Dissolved Carbon Dioxide mg/L CO₂ 0.05 - 50 mg/L +/- 10% +/- 1 mg/L 0.05 mg/L
Total Alkalinity mg/L CaCO₃ 10 - 325 mg/L +/- 10% +/- 10 mg/L 10 mg/L
Langelier Saturation Index -10 - 10.00 0.20 n/a n/a
Ryzner Stability Index 0 - 12.00 0.20 n/a n/a
Dissolved Inorganic Carbon mg/L CO₂ 1 - 200 mg/L +/- 10% +/- 1 mg/L 1 mg/L
Aggressive Index 7.00-15.00 +/- 0.20 n/a 7.00

* All the numerical values and percentages are subject to change.
